Fully automatic water storage tank production line:
1- Type: (3 layers).
2- Raw material: HDPE.
3- Capacity: 100~2000 Liter Maximum, Depended on the mold.
4- Output Capacity: 7-12Pcs per hour of 2000L storge tank.
5- Tank weight: Adjustable by controller.
6- Electrical Source: 220/380V,3phase 50/60Hz.
7- Current consumption: Clamping hydraulic motor: 30KW, Servo hydraulic motor: 4KW, Screw heating power: 80KW, Die head heating power: 80KW, Feeding machine power: 1.1KW.
8- Dimintions: 700CM*500CM, 570CM.
9- Weight: 35000Kg.

Useing: It is required to have a place divided into three sections: the raw materials section up to 100 meters at least, and the finished materials section up to 1000 meters at least. Production hall up to 140M at least.

Workers: 4 workers is enough for but its better to add one technical worker more.
